Machine for static and fatigue test on materials and components – customized software development


RTC-9001 Real Time Controller for static and fatigue test

RTC 9001 Real Time Controller for static and fatigue testThe RTC-9001 Real Time Controller is designed keeping in mind the need for laboratories and industries to easily perform static and fatigue test with a very powerful and cost effective system.
The RTC-9001 electronic is able to control any actuator equipped with a servo-valve or a servo-drive with analog input control in the range of ±10V, ±5V, 0-10V. Download the brochure for the Controller for Fatigue Test. Read more on the controller.


LiTEM Bicycle frame testing machine

bicycle test machineLiTeM is a trade mark by EnginLAB srl and DRC srl. Modular test frame are available to meet client needs and specifications. The RTC-9000 electronic is able to control any actuator equipped with a servo-valve or a servo-drive with analog input control in the range of ±10V, ±5V, 0-10V. Up to 4 actuators can be controlled simultaneously.

LiTeM – Life Testing Machines




LiTEM double column modular fatigue test machine

Fatigue test on fan blade by LiTeMLiTeM is a trade mark by EnginLAB srl and DRC srl. Double column modular test frame are available to meet client needs and specifications. The RTC-9000 electronic is able to control any actuator equipped with a servo-valve or a servo-drive with analog input control in the range of ±10V, ±5V, 0-10V. Up to 4 actuators can be controlled simultaneously.

LiTeM – Life Testing Machines

www.litem.info


RTC-9001 Pneumatic – powerful and user friendly software for testing

Software RTC 9001 for static and fatigue testEnginLAB has released the user interface software “RTC-9001 Pneumatic” a really powerful software able to easily perform static and fatigue test on materials and components. The Software is user friendly, check it on EnginLAB YouTube channel. The RTC-9001 training is completed in less than one hour. Read more on “Software for fatigue test, static test, stiffness test“.


Low friction Servo pneumatic actuator designed for fatigue test

servo pneumatic actuator low frictionLow friction servo pneumatic actuator with non contact displacement sensor internally integrated and load cell on the top of the cylinder rod. The analog output of the displacement sensor is 0-10V at full scale. The analog output of the load cell is +-10V at full scale.






Low friction Servo pneumatic actuator with recirculating ball guides designed for fatigue test

Low friction servo pneumatic actuator with recirculating ball guidesLow friction servo pneumatic actuator with ball recirculating guides to counter side loads. The external non contact displacement sensor give the instantaneous position feedback of the magnetic piston.






Simple aluminum frame for static and fatigue test

Simple frame for static and fatigue testOne column simple load frame composed of aluminum grooved profiles.

The distance (44mm) between the grooves is compatible with the fastening systems of the servo pneumatic actuators.

More complex load frame are designed on request.












Bike fatigue test frame

Bike fatigue test frameSimple aluminum test rig able to perform:

fork stiffness test

fork strength test

fork fatigue test.
